TCP/IP Ports Used by SAP Applications

技术资讯 6

SAP NetWeaver 全套服务端口参考表，包含 ABAP、AS Java、ICM、网关、消息服务器、TREX、MDM、数据库、SAProuter 等组件默认端口、端口范围与用途注释，用于 SAP 防火墙策略、网络规划、安全审计。

TCP/IP Ports Used by SAP Applications
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
NetWeaver Appl ication Serv er A BAP inclu ding Internet C onn ection Manager (ICM)
Dispatcher32NN sapdpNN+32003200-3299 sapdp00-sapdp99+SAP Dispatcher, used by SAP GUI for Windows and Java
Gateway33NN sapgwNN+33003300-3399 sapgw00-sapgw99+SAP gateway, used for CPIC and RFC communication
Gateway48NN sapgwNNs+48004800-4899 sapgw00ssapgw99s+SNC secured SAP gateway, used for CPIC and RFC communication, see SNC Users Guide for details, only encrypted communications. Please note, there is no related sapdpNNs (47xx) port
ICM HTTP80NN+8000FreeYou can configure the system to use port number 80 after installation.
ICM HTTPS443NN+Not activeFreeThe port is not configured during installation. If you want to use HTTPS, you must configure it manually.
ICM SMTP25+Not activeFreeThe port is not configured during installation. If you want to use SMTP, you must configure it manually. Only one instance per host should offer SMTP service.
Message Server36NN sapmsSID+3600 sapmsC11Free sapms<any SID>Only CI (central instance) Service names can be reassigned in /etc/services to an arbitrary value after installation. Relevant only for releases prior to  SAP NetWeaver 7.0
Message Server HTTP81NN+8100FreeOnly CI (central instance) Can be used to retrieve system information via HTTP Relevant only for releases prior to SAP NetWeaver 7.0
Message Server HTTPS444NN+Not activeFreeOnly CI  (central instance) The port is not configured during installation. Relevant only for releases prior to SAP NetWeaver 7.0
Central System LogUDP: 12NN, 13NN, 14NN, 15 NN+Not activeFreeSyslog (rslgsend) uses UDP for communications, see Note 25526 for deatils
Purely internal ports
Dispatcher32NN/UDP3200/UDP3200-3299/UDPOnly used on local host for signaling dispatcher, never seen on the network, disabled by default starting with 7.0 ( gw/use_udp=1 will enable UDP port )
Gateway33NN/UDP3300/UDP3300-3399/UDP+
ICM Admindetected automatically65000 or next free lower port65000 or lessInternal communication. Automatically uses the first free port from 65000 downwards. Port accepts connections only from localhost.
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
SAP NetWeaver  Application  Ser ver Java
JAVA EE Dispatcher ( replaced by ICM  in re lease SAP Net Weaver 7.1)
HTTP5NN00+5000050000-59900NN = Instance number (00…99)
HTTP over SSL5NN01+5000150001-59901
IIOP initial context5NN02+5000250002-59902
IIOP over SSL5NN03+5000350003-59903
P45NN04+5000450004-59904
P4 over HTTP tunneling5NN05+5000550005-59905Relevant only for releases up to and including  SAP NetWeaver 7.0
P4 over SSL5NN06+5000650006-59906
IIOP5NN07+5000750007-59907
Telnet5NN08+5000850008-59908
JMS5NN10+5001050010-59910Relevant only for releases up to and including  SAP NetWeaver 7.0
JAVA EE Server ( inte rnal ports)
Server Join Port5NN20 + x*550020 ( server  0)50020-59995+X = 0, 1, 2, 3, …15    (number of server)
Server Debug Port5NN21 + x*550021 ( server  0)50021-59996+X = 0, 1, 2, 3, …15    (number of server)
Central Services  for Java         ( Separate instan ce, default instance n umb er  01)
Enqueue Server
Enqueue Server Port32NN sapdpNN32013200-3299Provides locking services for AS Java NN = Instance number (00…99) enque/encni/port
Enq. Replication33NN sapgwNN33013300-3399Replication of enqueue data for high availability NN = Instance number (00…99) Releases up to NW2004s enque/encni/repl_port. Relevant  for releases up to and including SAP NetWeaver 7.0.
Enq. Replication5NN165011650016, …, 59916Replication of enqueue data for high availability NN = Instance number (00…99) enque/encni/repl_port Starting with NW2007
Gateway
Gateway33NN sapgwNN33013300-3399Only relevant for releases SAP NetWeaver 7.1 and higher. Ports used by SAP gateway for CPIC and RFC communication
Gateway48NN sapgwNNs+48004800-4899 sapgw00ssapgw99s+SNC secured SAP gateway, used for CPIC and RFC communication, see SNC Users Guide for details, only encrypted communications. Please note, there is no related sapdpNNs (47xx) port
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
Message Server
Message Server Port36NN36013600-3699NN = Instance number (00…99) rdisp/msserv
HTTP81NN+81018100-8199ms/http_port_<n>
HTTPS444NN+Not active44400-44499ms/https_port_<n>
SAP NetWeaver  AS  Adminis trat ive  Servic es
Host Control Service
SAPHostControl1128(+)112850013-59913+SAP Landscape Host integration service
SAPHostControlS1129(+)112950013-59913+NN = Instance number (00…99)
Start Service
Start Service5NN13 sapctrlNN+5001350013-59913+NN = Instance number (00…99) HTTP
Start Service5NN14 sapctrlsNN+5001450014-59914+NN = Instance number (00…99) HTTPS
Installation & upgrad e tools
SDM as part of AS instance5NN17 5NN18 5NN1950017 50018 50019+Software deployment manager Only CI (central Instance) NN = Instance number (00…99) Only NW04 and NW2004s
SL Controller5NN17 5NN18 5NN1950017 50018 50019+Used for patch and upgrade services *17:  Administrator Communication *18: GUI port *19:  http port NN = Instance number (00…99) NW2007
SAPinst SAPinst on IBM AS400 iSeries21212 21213 59975 5997621212 21213 59975 59976Free FreeSAPinst on IBM iSeries needs these additional ports.
Upgrade – Monitoring – UA-server (HTTP) – R3up-process – UA-server4238 4239 4240 42414238 4239 4240 4241Free
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
Utilities
SAProuter3299+3299Free
SAP Web Dispatcher – HTTP port – HTTPS portchose freely chose freely+FreeCurrently there is no installation procedure for SAP Web Dispatcher. Typical port for HTTP is 80. Typical port for HTTPS is 443
niping3298+3298FreeSAP network test program
SAPlpd515 printer+515FreeSAP printer spooler
RDBMS  (Database S ystems)
MS SQLChose freely14331024 – 5000+Port can be statically or dynamically allocated. If dynamic, port 1434/udp is also required.
Oracle   listener15271527Freeconfigured in listener.ora and tnsnames.ora
IBM DB6  (AIX) DB2  (OS/400)50000 4402 / as-edrsql50000 4402FreeConflicts with SAP JAVA EE Engine with instance number 00. See relevant documentation on how to change this DB6 default port.
liveCache (MaxDB) (formerly know as SAP DB) Webtools7200 / sql30 7210 / sql6 7269/sapdni72 7270/sdbnissl76 7575 / SDB+ + +7200 7210 7269 7270 7575FreeIn case of multiple MaxDB instances on one host the services are shared by all instances.
NWDI  (NetWeaver De velopment Infras truc ture)
DTR5NN1550015Design Time Repository (NW2004s and later) NN = Instance number (00…99)
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
SAP NetWeaver  AS  Adminis trat ive  Servic es
ITS  (Internet Transac tion Server)
AGate39N0-39NM / sapavw00_Inst3900 – 390MFreeN determined at setup so that range free M = No agates –1 Inst = Name of ITS Instance
MM39N9 / sapavwmm_Inst3909FreeMapping Manager
IGS (Internet Graphic s Server) as part  of A pplication Serv er Instance
Multiplexer4 NN 00
Portwatcher (Clients)4 NN01-4NN 79
HTTP-ports4 NN80-4NN 99
XI  (SAP Exchange Inf rastructure)
JMS/JDBC/File Adapter Server8200 (8201, … for multiple Adapter Installations on same host)+8200 (Rules for this adapter not yet implemented)FreePort used for interactive browser access to configuration interface. Adapter does not belong to an SAP Application Server system. It can be installed on a host with XI server, or standalone. Usually only one instance needed, because individual JMS/JDBC and File Adapter instances live inside one serve process.
JMS AdapterChose freely8210FreePort for incoming data from XI server.
JDBCAdapterChose freely8220FreePort for incoming data from XI server.
File AdapterChose freely8230FreePort for incoming data from XI server.
IPC (NW05 and CRM  5.0)   (Internet Pri cing  and Configura tor)
IPC Dispatcher4363+4363FreeMobile client
IPC Version 3.0 and 4. 0   (Internet Prici ng a nd Configurato r)
IPC Dispatcher4444+4444FreeMobile client
IPC data loader4445Not activeFree
IPC Server9999, 9998, …9999FreeCounting down from 9999 for each server process.
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
TREX   (Text Retrieval  and Information  Ext raction)
Name Server3NN013000130001-39901NN = TREX Instance; available for TREX 6.1, TREX 7.0, TREX 7.1
Pre Processor3NNx23000230002-39992multiple servers possible x=server-index (0,1,2,…,9); available for TREX 6.1, TREX 7.0, TREX 7.1
Index Server3NNx33000330003-39993multiple servers possible x=server-index (0,1,2,…,9); available for TREX 6.1, TREX 7.0, TREX 7.1
Queue Server3NNx43000430004-39994multiple servers possible x=server-index (0,1,2,…,9); available for TREX 6.1, TREX 7.0, TREX 7.1
HTTP Server3NN053000530005-39905available for TREX 6.1, TREX 7.0, TREX 7.1
GRMG service ( Heartbeat )3NN063000630006-39906optional; available as of TREX 7.0
RFC Server3NN073000730007-39907Multithreaded RFC server with port 3 NN07 available as of TREX  7.0
Cruiser3NNx83000830008-39908multiple servers possible x=server-index (0,1,2,…,9); available as of TREX 7.1
Alert Server3NN113001130011–39911available as of TREX 7.0
BackupServer3NN173001730011-39917optional; available as of TREX 7.1
MDM  (Master Data M anagement)
Admin Console20003+20003Fixed+Communication between Admin Console application and MDM server
Server to Server2000420004Fixed+Inter Server communication ( master/slave )
Admin Console20005+20005Fixed+Communication between Admin Console application and MDM server
Import Manager20006(+)20006Fixed+Communication between MDM Import Manager Service and its clients
Syndicator Service20007(+)20007Fixed+Communication between MDM Syndicator Service and its clients
Layout Server31596, 31597, 31604+31596, 31597, 31604Fixed+Communication for print publishing between MDM Layout Server and its clients
Layout Server Quark Express31602+31602Fixed+Communication for print publishing between MDM Layout Server and Quark Express plugin
Layout Server Adobe InDesign31603+31603Fixed+Communication for print publishing between MDM Layout Server and Adobe InDesign plugin
Layout Server31596+31596Fixed+Communication for print publishing between MDM Layout Server and its clients
MDM Server2000-2002+2000-20022000-99973 consecutive ports in this range are required per each repository
ServicePort Number / Service Name RuleDefaultRange ( min-max )Comment
TREX 6.0  (Text Retrie val and Informat ion  Extraction)
Name Server83558355Free
Pre Processor83578357Free
Index Server83518351Free
Queue Server83528352Free
Http Server83538353Free
Monitoring (GRMG)83668366FreeAvailability monitoring in CCMS
Content Server
Content Server1090+1090Free
Cache Server1095+1095Free
CRM
CSDM20201+FreeCentral Software deployment manager
Exchange Groupware Connector  (DCOM)135  /  DCEDCOM uses port 135 for the Service Control Manager which allocates a free port for the application.
Lotus Domino
– Connector – Proxy62026 – 62029 62126 – 62129+62026–62029 62126-62129Free FreeThe range comprises 4 Instances xxx26 for instance 1 up to xxx29 for instance 4.
PAW  (Performance A ssessment Work ben ch  of Knowled ge Warehouse)
PAW Communication Server1099+1099FreeJava RMI Server
PAW Servlet Engine1089+1089Free
Business One
httpFree+80FreeIIS, configurable port on client side
ODBC  (e.g. MSSQL)Free1433FreePort can be statically or dynamically allocated. If dynamic, port 1434/udp is also required.
DCOM135  /  DCEConnection to license server.
DCOM uses port 135 for the Service Control Manager which allocates a free port for the application.
